Cold Cutting Saw

The patented system for the cold cutting of steel.


The modular design allows for multifunctional application. Short set-up times and high cutting performance ensure added value. The cold cutting system is suitable for dry and wet cutting. The cold cutting system is also suitable for underwater operations (according to IP 68-Code). Specially coated saw blades enable cutting depths of up to 530 mm. Thus, it can cut high-alloy steels, lead, copper, and many other materials via a cold cutting process. Remote operation and fully automatic control are possible, so that a high occupational safety is ensured.

Choose a product from the range Cold Cutting Saw

BKS12 HS

The hydraulically driven cold cutting saw assists you with all types of cutting. Efficient processing due to the simple operation and assembly.

Its Advantages

  • high cutting performance in comparison to wire saws
  • light weight and mobile
  • remote controllable
  • suitable for implementation underwater
  • can also be used for dry processing
  • cuts high-alloy steel, copper, lead, casting material, and a lot more
  • spark-free cold cutting process

Do you have questions about our product or want to place an order?
Contact us - our competent staff will be pleased to advise you!

Technical Data

max. saw blade diameter

1200 mm

max. cutting depth

530 mm

max. drive power

up to 26 kW

max. operating pressure

260 bar

max. oil stream

60 l/min

swivelling range of saw arm

360°

feed drive & delivery

electric, fully autom.

tool drive

hydraulic

weight of saw head without hydraulic motor

33.0 kg

weight of hydraulic motor

5.5 kg

type of protection

IP 68

Accessories

  • Camera system
  • Screen protection with nozzles for cooling the blade
  • Specially coated saw blades
  • Guide rails
  • Possibilities for rail fastening
    • Vacuum plates
    • Magnetic base
    • Hydraulic rail clamps
  • Diagonal cut rail brackets
  • Rail connectors
